The KANN series is a portable player lineup loved by audiophiles all over the world for its performance focused on high output and clear sound. KANN MAX, the fourth product in the KANN series, builds on the advantages of the KANN series with higher output and portability. It provides 4 levels of gain and up to 15Vrms output so that a wide array of headphones can be driven in an optimal state.

 By integrating the proven design of the KANN series into a lighter-weight and smaller-sized player, we have realized both ultra-high output and low noise. KANN MAX features ESS ES9038Q2M Quad-DAC together with Astell&Kern's unique audio technology to provide the best performance you can feel from a portable DAP.

• Model

  KANN MAX

• Body Color

  Anthracite Gray, Brown Mud

• Body Material

  Aluminum

• Display

  4.1-inch 720 x 1280 touch screen

• Supported Audio Formats

  WAV, FLAC, WMA, MP3, OGG, APE, AAC, ALAC, AIFF, DFF, DSF, MQA

• Sample Rate

  PCM : 8kHz ~ 768kHz (8/16/24/32bits per Sample)
  DSD Native: DSD64(1bit 2.8MHz), Stereo / DSD128(1bit 5.6MHz), Stereo / DSD256(1bit 11.2MHz), DSD512(1bit, 22.4MHz) Stereo

• Output Level

  [Low] Unbalanced 2Vrms / Balanced 4Vrms (Condition No Load),
  [Mid] Unbalanced 4Vrms / Balanced 8Vrms (Condition No Load),
  [High] Unbalanced 6Vrms / Balanced 12Vrms (Condition No Load),
  [Super] Unbalanced 8Vrms / Balanced 15Vrms (Condition No Load)

• CPU

  Quad-core

• DAC

  ESS ES9038Q2M x4 (Quad-DAC)

• Decoding

  Support up to 32-bit/768kHz Bit-to-Bit Playback

• Input

  USB Type-C input (for charging & PC & MAC)

• Outputs

  Unbalanced Out (3.5mm), Optical Out (3.5mm)
  Balanced Out (2.5mm, only 4-pole supported | 4.4m, only 5-pole supported)

• Wi-Fi

  802.11 b/g/n (2.4GHz)

• Bluetooth

  V5.0 (A2DP, AVRCP, Qualcomm® aptX™ HD, LDAC)

• Dimensions

  2.68"(68.3mm)[W] x 4.6"(117mm)[H] x 0.92"(23.6mm)[D]

• Weight

  about 10.76oz (305g)

• Feature Enhancements

  Firmware upgrade supported (OTA)

• Operating Temperature

  0℃ ~ + 40℃ (32℉~ 104℉)
