After successfully launching the AK100 and the AK120 models, we asked ourselves, “What is the ultimate sound quality?” After much consideration, we decided to move a step further with our goal, which is to deliver the sound “exactly as the artist had intended” for us to hear.

Moving from the AK100 to the AK120, we decided to provide a Dual DAC setup to create better left and right channel separation with clearer sound quality.

We thought that the Dual DAC setup would be enough, but while developing the AK240, we felt the need to further improve sound quality to accurately reproduce the original sound recording. After countless hours of research and testing, we were able to find the answer.

The answer was to create both a balanced output and native DSD playback through the Dual DAC setup.

Now with the AK240, we can dare say that we have gotten “that much closer” to the sound quality of the original recording.

• Model

  AK240

• Body Color

  Gun Metal

• Body Material

  Aircraft Grade Duralumin

• Display

  3.31inch WVGA (480 x 800) AMOLED Touchscreen

• Supported Audio Formats

  WAV, FLAC, WMA, MP3, OGG, APE(Normal, High, Fast), AAC, ALAC, AIFF, DFF, DSF

• Sample rate

  FLAC, WAV, ALAC, AIFF : 8kHz ~ 192kHz (8/16/24bits per Sample) / DSD Native : DSD64 (1bit 2.8MHz), Stereo / DSD128 (1bit 5.6MHz), Stereo

• Output Level

  Unbalance 2.1Vrms / Balance 2.3Vrms (Condition No Load)

• DAC

  Cirrus Logic CS4398 x2 (Dual DAC)

• Decoding

  Support up to 24bit/192kHz Bit to Bit Decoding, DSD64/128

• Input

  USB Micro-B input (for charging & data transfer (PC & MAC)) / Connection Mode: MTP (Media Device)

• Outputs

  PHONES (3.5mm) / Optical Out (3.5mm) / Balanced Out (2.5mm, only 4-pole supported)

• Wi-Fi

  802.11 b/g/n (2.4GHz)

• Dimensions

  2.59 ”(66 mm) [W] x 4.21 ”(107 mm) [H] x 0.68 ”(17.5 mm) [D]

• Weight

  6.5 oz (185 g)

• Feature Enhancements

  Firmware upgrades supported (OTA)
